MAN-30W
CNMANLASER
I Product Introduction:
CO2 laser Marking Machine is specially designed for non-metallic materials marking. It is equipped with the original imported Amercian CO2 laser and high-speed galvanometer with unique fully sealed cavity construction.
The working principle: fill the discharge tube with CO2 gas as a lasing medium, when high voltage is applied to the electrodes, radiant discharge is generated in the discharge tube, causing the gas molecules to release the laser. After amplification, the laser beam is released for material processing. With computer controlling the galanometer, the laser beam is adjusted for automatic marking.
II Product Features:
-High-precision marking, high speed operation, control marking depth freely.
-No pollution, no consumables.
-Marking software runs on WINDOWS XP platform, English or Chinese interface, compatible software such as AUTOCAD, CORELDRAW, PHOTOSHOP and various formats such as PLT, PCW, DXF, BMP etc. It can also directly access to SHX, TTF fonts library and able to work freely o graphic design.
| Model | CO2 Fly laser marking machine |
| Laser Power | 30W 55W 100W |
| Laser Wavelength | 10640nm |
| Repetition Frequency | ≤70KHz |
| Marking Area | 110mmx110mm |
| Marking Depth | ≤2mm(Adjustable with different material |
| Marking Speed | ≤7000mm/s |
| Min. Line Width | 0.03mm |
| Min. Character Size | 0.3mm |
| Repetition Accuracy | ±0.001mm |
| Power Consumption | ≤1.2Kw |
| Power Supply | 220v/50Hz/10A |
| Cooling Method |
Product Application:
Mainly used in non-metallic industry including tobacco, food and beverage, wine, pharmaceutical packaging, leather, plastics, polymers, wooden products, jade, agate and other non-metallic materials.
