ruida controller 6445 board for engraving machine spare parts
Product parameters :
Model | RUIDA control panel |
Type | Industrial equipment |
Voltage level | low voltage |
Rated current | 2A |
Rated voltage | 24V |
Voltage regulation accuracy | 80% |
Current accuracy | 80% |
Ripple factor | 95% |
Offline | Yes |
Color display | Yes |
Max speed | 1500MM/S |
Network transmission | Yes |
Feature :
RuIDA system is the lastest laser engraving & cutting control system developed by Ruida Technology, this control system has better stable hardware with anti-static, resistance to high pressure.
Based on 3.5-inch colorful screen human-machine operation system, with better operation interface and stronger functions, exellent motion control functions, high-capacity file memory,
with strong compatible 2-way independent adjustable laser power control interface, strong U disk drive program, multiple ways general/dedicated IO control.
1.Digital laser control signals:
(1) TTL level output, 50 mA,drive capability(can set enable signal polarity in software)
(2) PWM frequency 2K-50K for adjustable
(3) PWM duty ratio is 1% ~ 99%, adjustable
(4) PWM value is up to 5.0 V
2.Motor control signal:common-anode output, drive capability 20 mA
Motor control pulse frequency: Max.500KHZ
3.USB: Max. transmission rate 12M bps; The longest distance is 5 meters.
4.Network:Max. transmission rate is100M; Max. transmission distance is 200M.
5.Interpolation:Linear/circular arc/B spline, accuracy + / - 0.5 pulse
6.Output: 4-channel, photoelectric isolated OC gate output, the max. drive capability 500mA drive capability
(with follow-current protection)
7.Input:4-channel, photoelectric isolated input, compatible with 5V/ 12V / 24V logic level
