MAN-80
Marking Material
-Metal ( Gold, silver, brass, copper, Iron, aluminum, titanium, zinc, steel...)
-Plastic (PC,PVC,PE,HDPE,ABS,PPR,PET,HIPS,PS,PP,PPO,PA,POM,PMMA...)
-Others (Oil paint surface, coating surface, plastic film, package...)
| Laser type | Fiber laser | ||
| Laser source | RAYCUS | ||
| Galvanometer | High speed (double red focusing light and alarm lamp) | ||
| Lens | F-Theta lens (110X110mm) | ||
| Wavelength | 1064nm | ||
| Max Single pulse energy | 1.0mj | 1.0mj | 0.6mj |
| Pulse duration | 90-150ns | 90-130ns | 90-130ns |
| Laser beam quality M2 | <1.6 | <1.5 | <1.5 |
| Frequency | 50-100KHZ | 30-60KHZ | 30-60KHZ |
| Marking speed | 8000mm / s | ||
| Marking Depth | 0.01-1mm | ||
| Controller | BJJCZ- EZCAD software | ||
| Control program | XP/ WINDOWS 7/8/10 | ||
| Marking Area | 110mm×110mm (optional) | ||
| Spot size | 27.5μm | ||
| Graphic format supported | JPG,BMP,DXF,PLT,AI | ||
| Working voltage | AC220V 50HZ or AC110V 60HZ | ||
| Cooling type | Air cooling | ||
| Operating parameter | 0-40ºC | ||
| Warranty | 2 years | ||
Famous Fiber Laser SourceBrand: RAYCUS or MAX or JPT or IPG
Famous brand laser, maintenance-free, three-year warranty, better laser quality, also very popular in the world
Digital galvanometer
Brand: CHINA
Added double red-focus-lights and warning light, finding focal length is more convenient.
High repeatability, high scanning speed.
Marking Material
-Metal ( Gold, silver, brass, copper, Iron, aluminum, titanium, zinc, steel...)
-Plastic (PC,PVC,PE,HDPE,ABS,PPR,PET,HIPS,PS,PP,PPO,PA,POM,PMMA...)
-Others (Oil paint surface, coating surface, plastic film, package...)
| Laser type | Fiber laser | ||
| Laser source | RAYCUS | ||
| Galvanometer | High speed (double red focusing light and alarm lamp) | ||
| Lens | F-Theta lens (110X110mm) | ||
| Wavelength | 1064nm | ||
| Max Single pulse energy | 1.0mj | 1.0mj | 0.6mj |
| Pulse duration | 90-150ns | 90-130ns | 90-130ns |
| Laser beam quality M2 | <1.6 | <1.5 | <1.5 |
| Frequency | 50-100KHZ | 30-60KHZ | 30-60KHZ |
| Marking speed | 8000mm / s | ||
| Marking Depth | 0.01-1mm | ||
| Controller | BJJCZ- EZCAD software | ||
| Control program | XP/ WINDOWS 7/8/10 | ||
| Marking Area | 110mm×110mm (optional) | ||
| Spot size | 27.5μm | ||
| Graphic format supported | JPG,BMP,DXF,PLT,AI | ||
| Working voltage | AC220V 50HZ or AC110V 60HZ | ||
| Cooling type | Air cooling | ||
| Operating parameter | 0-40ºC | ||
| Warranty | 2 years | ||
Famous Fiber Laser SourceBrand: RAYCUS or MAX or JPT or IPG
Famous brand laser, maintenance-free, three-year warranty, better laser quality, also very popular in the world
Digital galvanometer
Brand: CHINA
Added double red-focus-lights and warning light, finding focal length is more convenient.
High repeatability, high scanning speed.
